Flake Ice Maker

Category： Ice Maker
Brand:Shu Yu
Name：Flake Ice Maker
Shu Yu fully automatic snow ice machine is a new generation of snow ice machine. According to the ice requirements of the industry, it adopts high-eﬃciency ﬂuorine-free imported compressors, mechanica
INQUIRY EMAIL

Shu Yu fully automatic snow ice machine is a new generation of snow ice machine. According to the ice requirements of the industry, it adopts high-eﬃciency ﬂuorine-free imported compressors, mechanical rotary extrusion ice making method, and computer-controlled fully automatic ice making. The ice made is irregular, ﬁne and granular snowﬂake crushed ice.

Operating principle
The incoming water is ﬁltered and then passes through the spiral evaporator. In the evaporator, it absorbs heat and vaporiz- es at a low temperature of -18°C, causing the water to quickly condense into ice. Then the gear reducer drives the ice blade in the evaporator to rotate, and is extruded through rotation It will be transported to the ice outlet and fall freely into the ice storage tank under the action of gravity.

Accessories

Parameters

Model	Capacity (kg/24h)	Ice storage capacity	Input power (W)	Refrigerants	Dimensions(mm)
XB-20II	20	15	240	R134a/80g	420x580x735
XB-30II	30	15	240	R134a/80g	420x580x735
XB-40II	40	15	240	R134a/80g	420x580x735
XB-50II	50	15	240	R134a/80g	420x580x735
XB-70II	70	25	420	R404a/120g	600x600x830
XB-85II	85	25	420	R404a/120g	600x600x830
XB-130II	130	32	600	R404a/160g	600x700x830
XB-150II	150	32	600	R404a/160g	600x700x830

Features

Application scenarios

● Hospitals, laboratories, schools and other medical research places
● Restaurants, bars, hotels and other entertainment venues
● Fishing, chemical industry, food processing and other industries that require large amounts of ice
