Industrial food freeze dryer

Category： Industrial Freeze Dryer
Brand:Shu Yu
Name： food freeze dryer SCIENTZ-SG
Industrial food freeze dryer Durable & Hygienic: Entire interior crafted from stainless steel for long-lasting performance and easy cleaning.
INQUIRY EMAIL

Product Highlights
1. Full Stainless Steel Chamber
Durable & Hygienic: Entire interior crafted from stainless steel for long-lasting performance and easy cleaning.
High Standards: Meets stringent processing requirements for labs and production environments demanding strict environmental control.

2. Eco-Friendly Refrigeration Technology
Sustainable Cooling: Uses R404a refrigerant paired with high-efficiency piston/screw compressors (international brands).
Energy Efficient: Balances superior cooling performance with reduced environmental impact.

3. Constant-Temperature Shelf System
Precision Control: Maintains stable temperatures during freezing and sublimation for consistent, reliable results.
Process Stability: Ensures uniform sample treatment critical for reproducible outcomes.

4. Enhanced Vacuum System
High Performance: Combines vacuum pumps + Roots pumps with oil-water separation for faster drying cycles.
Protection: Minimizes oil contamination, extending equipment lifespan.

5. High-Efficiency Condenser & Rapid Defrost
Superior Water Capture: Optimized condenser design maximizes vapor trapping.
Time-Saving: Quick-defrost feature reduces downtime and boosts productivity.

6. Optional Automated Loading System (AGV)
Smart Automation: AGV carts enable hands-free material transfer, improving safety and workflow efficiency.
Customizable: Adapts to your production line for seamless integration.

Why Choose This Freeze Dryer?
Lab & Industrial Use: Ideal for pharmaceuticals, biotech, and food science.
Future-Ready: Scalable with automation for growing demands.
Reliability + Sustainability: Combines precision with eco-conscious design.

This version:
Uses clear, concise bullet points for readability.
Highlights key benefits (e.g., time-saving, compliance).

Emphasizes USPs like automation and environmental specs.

Technical Parameters

Product	food Freeze Dryer SCIENTZ - SG
Model	5SG	10SG	20SG	30SG	50SG
Parition area (m²)	5	10	20	30	50
Loading (Kg)	75	150	300	450	750
	Length (mm)	1300	1400	1900	2280
Partition area (m²)	Width (mm)	786	886	1186	1196
	Height (mm)	10	10	10	10
Partition layer quantity (pieces)	5 + 1	8 + 1	9 + 1	11 + 1	(13 + 1)*2
Inner diameter of barrel (mm)	1280	1280	1800	1800	2050
Partition spacing (mm)	70	70	70	70	70
Plate temperature range (°C)	- 50 - + 60
Partition temperature difference (°C)	±1
Cold trap minimum temperature (°C)	≤ - 70
Cold trap water capture capacity (Kg)	75	150	300	450	750
Ultimate vacuum (Pa)	2.0
Installed power (Kw 380V/50Hz)	16	26	52	86	132
Length (mm)	3250	5100	7000	7800	12000
Width (mm)	1600	1600	2000	2100	2300
Height (mm)	2200	2300	2800	2900	3800
Equipment weight (approximately kg)	2500	3700	7000	9000	12000
