Entry-level Biological microscope ML11

Category： Biological microscopes
Brand:Shu Yu
Product name：Entry-level Biological microscope ML11
Application ：biology, agriculture,Research Institutes, Colleges and Universities, Healthcare, Biomedicine
INQUIRY EMAIL

Description

Biological microscope ML11 is a basic optical microscope equipped with plan achromatic objectives and wide field eyepiece, featured with
clear view, wide field and easy operation. It is quite popular for teachers and students to achieve interactive teaching on biology science. The
biological microscope is widely used in the fields of biology, agriculture and it is an ideal instrument for education departments.

Feature

Sample images

Specifications

Parts	Specification	Standard	Optional
Eyepiece	WF10X/20mm	・
	WF10X/18 (with eyepiece pointer)		・
Observation tube	30°inclination,hinged trinocular observation head, interpupillary distance 50mm - 75mm，single type diopter adjustable, fix light division R:T:80:20	・
Nosepiece	Quadruple nosepiece with inward tilt	・
Objectives	Achromat objective 4X/0.10, W.D.: 37.5mm	・
	Achromat objective 10X/0.25,W.D: 6.55mm	・
	Achromat objective 40X/0.65,W.D: 0.669mm	・
	Achromat objective 100X/1.25, W.D: 0.198mm	・
	ACH 20X		・
Focus system	Low position hand wheel coaxial coarse and fine adjustment with limit stopper and lock device	・
	Stage height movement (coarse movement stroke: 25mm)	・
	Fine focusing accuracy 0.002mm	・
Stage	155mmx142mm double layer compound mechanical moving stage, moving range 76mmX50mm, accuracy 0.1mm	・
Transmitted illumination system	3W LED, Pre - set lamp center, brightness continues adjustable	・
